The RS232 interface, used for CT, CTlaser, and CTratio pyrometers, is a robust and flexible communication standard for infrared temperature monitoring in industrial environments. Operating in a full-duplex mode over three wires (Tx, Rx, and GND), it provides reliable data transmission up to 15 m. The RS232 standard typically operates at baud rates up to 115.2 kbps. This interface allows for precise and efficient infrared temperature data collection, which is essential for applications requiring digital infrared temperature readings.
The RS232 interface, used for CT, CTlaser, and CTratio pyrometers, is ideal for industrial infrared temperature monitoring. It operates in full-duplex mode over three wires (Tx, Rx, and GND) for reliable data transmission up to 15 m. Typical baud rates are up to 115.2 kbps, ensuring precise and efficient infrared temperature readings.
General Specifications
Environmental rating: IP67 (Nema-4) (when installed)
Operating temperature: -20 °C to 80 °C
Relative humidity: 10 – 95 %, non-condensing
Interface Board Characteristics
Port protocol: serial communication
Transfer speed: up to 115.2 kbps
Physical layer: RS232 (3-wire)
Maximal number of devices in network: Single-device communication
Connector: D-Sub, 9 Pin, female connector
