Mounting bracket CxL/ CxV/ CSvision, adjustable in one axis, stainl. steel, with tripod thread

Made for the CTlaser, CSlaser, CTvideo, CSvideo, and CSvision Infrared Pyrometer

The IR Sensor Mounting Bracket adjustable in one axis is an essential accessory for ensuring the optimal performance of CTlaser, CSlaser, CTvideo, CSvideo and CSvision infrared sensors. With its durable stainless steel construction and adjustable design, it offers a reliable and flexible mounting solution for a variety of industrial applications.

  • Material: Stainless steel
  • Connection hole: 6.5 mm diameter
  • Operating temperature range: Same as the sensing head

The IR Sensor Mounting Bracket adjustable in one axis is an essential accessory for ensuring the optimal performance of CTlaser, CSlaser, CTvideo, CSvideo and CSvision infrared sensors. With its durable stainless steel construction and adjustable design, it offers a reliable and flexible mounting solution for a variety of industrial applications.

General Specifications

  • Size: 60 x 87 x 60 mm (L/W/H)
  • Thickness: 4mm
  • Material: stainless steel
  • Operating temperature range: Same as the sensing head
  • Single Axis Adjustability: The mounting bracket allows precise adjustment along one axis, providing flexibility in positioning the infrared sensor to achieve optimal alignment and performance.
  • Durable Construction: Made from corrosion-resistant stainless steel, the bracket is built to withstand harsh conditions, ensuring reliability and durability in demanding applications.
  • Easy Installation: The bracket is designed for straightforward installation, featuring a user-friendly design that simplifies the process of mounting and adjusting the infrared sensor.
  • Compatibility: The mounting bracket is compatible with a wide range of infrared sensors, making it a versatile choice for various industrial applications.

Thermography software optris PIX Connect is included and license-free.All infrared cameras are delivered with the thermography software optris PIX Connect, developed specifically for the extensive documentation and analysis of thermal images. The Windows-based PIX Connect software enables users to tailor the infrared cameras to meet specific requirements. It analyses live and recorded temperature data and triggers alarm signals for process integration.The key to leveraging the Optris infrared camera is a correct configuration. This includes detailed device-specific configurations such as frame rate, measurement range adjustments, external communication settings, and USB/Ethernet configurations. Moreover, PIX Connect facilitates firmware updates and the download of configuration files over the Internet.

Optris offers several different SDKs for our Xi and PI thermal imaging cameras. Depending on the operating platform, the infrared camera, the coding language, and the hardware platform, different software interfaces can be utilized:

The Optris IRmobile allows users to set up and commission an Optris infrared pyrometer or infrared camera with an Android smartphone or tablet. This tool becomes handy for commissioning and aligning the infrared camera‘s field of view or adjusting the configuration. The app analyzes the connected infrared camera‘s live infrared image stream with auto hot and cold spot detection. For pyrometers, a temperature-time diagram or the video signal is displayed. This app works on most Android devices running 5.0+ with a USB port supporting USB-OTG (On The Go).
