The Optris CTlaser 1M series is an advanced infrared thermometer known for its high performance and precision in very high-temperature measurement applications, such as molten steel, tungsten, iron, nickel, and semiconductors. Featuring double laser spot marking, a stainless steel sensing head (M48x1.5), and separate configurable electronics, this pyrometer ensures adaptability and accuracy across various applications. Having a two-piece design allows for straightforward installation, facilitating cost-effective mechanical integration.
In terms of spectral range and optical resolution, the CTlaser 1M series operates at a specialized range of approximately 1.0 µm, making the IR sensor a reliable choice for accurate temperature measurement in hot applications. The high optical resolution, ranging from 150:1 to 300:1 depending on the model, is crucial for measuring temperatures of very hot, shiny materials with reduced sensitivity to emissivity variations.
Covering temperatures from 485 °C to 2200 °C, the series is suitable for extremely high-temperature environments. With response times starting from 1 ms, the CTlaser 1M series excels in dynamic processes requiring rapid temperature measurements.
The Optris CTlaser 1M stands out with its double laser aiming marks, which precisely indicate the real spot location at any distance, enhancing accuracy in temperature monitoring. Unlike conventional IR thermometers with single lasers that mark only the center of the spot, the CTlaser 1M’s innovative double laser sighting system provides valuable aiming support into the spot size and ensures accurate alignment.
Constructed with a stainless steel sensing head and a two-piece design including a separate electronics box, the CTlaser 1M series offers durability and advanced signal processing capabilities. This infrared pyrometer can be used in ambient temperatures up to 85 °C without requiring cooling, with the laser automatically switching off at 50 °C to protect the system.
For output and integration, the CTlaser 1M series offers a wide array of analog and digital outputs, including 0/4 – 20 mA, 0 – 5 V, 0 – 10 V, USB, RS485, RS232 interface, relay outputs (2 x optically isolated), Profibus DP, Modbus RTU, Modbus TCP, Profinet, and EtherNet/IP. This versatility allows for seamless integration into various industrial processes and monitoring systems.
Enhanced with Optris accessories such as air purging and mounting flanges, the CTlaser 1M pyrometer is designed for integration into a wide range of manufacturing and process applications. These pyrometers undergo meticulous calibration in Germany to meet government standards such as PTB or NIST, ensuring accuracy and reliability. Optris provides comprehensive support, including consultation on industrial applications and after-sales assistance, ensuring optimal performance and user satisfaction.
The CTlaser 1M series is particularly suited for hot metal processing and diverse industrial environments where precise, reliable, and fast temperature measurement is critical. With its combination of precision, versatility, and reliability, the CTlaser 1M pyrometer stands out as a valuable tool for demanding industrial applications.
| MODEL | CTlaser 1ML | CTlaser 1MH | CTlaser 1MH1 |
| DETECTOR | |||
| Detector | Si | ||
| Spectral Range | 1.0 µm | ||
| Response Time (90% energy) | 1 ms | ||
| Sampling Frequency | 1000 Hz | ||
| OPTICAL & SIGHTING | |||
| Distance to Spot (D:S) | 150:1 | 300:1 | |
| Spot size (SF optics) | 7.3 mm @ 1100 mm | 3.7 mm @ 1100 mm | |
| Laser Sighting | Double point laser (635 nm) | ||
| Focus | Fixed | ||
| MEASUREMENT | |||
| Measurement Range | 485 ... 1050 °C | 650 ... 1800 °C | 800 ... 2200 °C |
| Accuracy | ±(0.3 % of reading + 2 °C) | ||
| Repeatability | ±(0.1 % of reading + 1 °C) | ||
| Thermal Sensitivity (NETD) | 100 mK | ||
| Emissivity / Reflectivity | 0.100 – 1.100 | ||
| INTERFACES & SIGNAL PROCESSING | |||
| Interface | USB / RS232 / RS485 / Profibus / Ethernet / Relay | ||
| Direct Output | 0/4 – 20 mA, 0 – 5/10 V, t/c K/J | ||
| Signal Processing | Average, Peak hold, Valley hold, Advanced peak hold | ||
| GENERAL SPECIFICATIONS | |||
| Sensing Head Size | Ø50 mm x 100 mm, M48x1.5 | ||
| Operating Temp (Head) | -20 °C ... 85 °C (50 °C with laser ON) | ||
| Operating Temp (Electronics) | -20 °C ... 85 °C | ||
| Protection Class | IP 65, NEMA 4 | ||
| Power Supply | 8-36 V DC / 5 V USB | ||
