Air Purge Laminar for CoolingJacket Advanced

Ensuring Clear Optics and Accurate Infrared Measurements

The Laminar Air Purge for Cooling Jacket Advanced ensures clear optical paths and accurate temperature measurements by keeping the infrared sensor lens clean in rugged industrial environments. It effectively shields the lens from dust, smoke, and fumes. Constructed from anodized aluminum, it includes a protective window tailored to the IR sensor’s spectral sensitivity. Its unique laminar airflow design ensures a uniform, steady stream of air, preventing dust accumulation on the lens edges. Unlike other air purges, it offers superior protection and reliability for infrared measurements. Additionally, a special version for line scanners is available, featuring a reduced aperture to minimize the risk of lens-damaging cracks from debris, ensuring long-lasting performance and durability.

  • Protects from dust, smoke, fumes
  • Compatible to the Cooling Jacket Advanced
  • Focusable from the outside
  • Easy maintenance due to folding mechanism
  • Laminar airflow design ensures no dust accumulates on the lens

The Laminar Air Purge for Cooling Jacket Advanced protects the infrared sensor lens in rugged industrial environments, ensuring clear optical paths. It shields from dust, smoke, and fumes, crucial for accurate temperature measurements. Made from anodized aluminum, it includes a protective window tailored to the IR sensor’s spectral sensitivity. Its unique laminar airflow prevents dust accumulation, ensuring reliability in infrared measurements.

General Specification

  • Operating temperature: 0 … up to 315 °C (with water cooling)
  • Storage temperature range: 0 … 80 °C
  • Environmental rating: IP65
  • Relative humidity: 10 – 95 %, non-condensing
  • Material: Anodized aluminum
  • Weight: 1.9 kg
  • Size: 200 x 189 x 43 mm

Air purge

  • Airflow: 40-120 l/min
  • Absolute pressure: 1.1-10.0 bar
  • Condition: Use oil-free, technically clean air only
  • Coupling plug for the air: NW7,2-G1-8-AG MSV

SKU’s

ACCJAAPLFL
ACCJAAPLS
ACCJAAPLL
ACCJAAPLFS

  • Laminar Air Purge is an extra accessory for the Cooling Jacket Advanced, and it is supplied individually.
    The Protective window has to be ordered separately.
  • ACCJAAPLFL, ACCJAAPLS, ACCJAAPLL, ACCJAAPLFS
